GI Pipe Earthing Electrode with Salt & Charcoal

Product Overview: GI (Galvanized Iron) Pipe Earthing is one of the most widely used and economical grounding systems designed to provide a low-resistance path to dissipate fault current safely into the earth. It is a traditional and proven method for earthing used across residential, industrial, and commercial installations. 🔧 Construction & Installation Electrode Material: High-quality hot-dip galvanized iron (GI) pipe — corrosion-resistant and durable. Typical Dimensions: 40 mm, 50 mm, 76 mm, or 100 mm diameter 2 m or 3 m length (as per site requirement) Filling Material (Backfill): A mixture of salt and charcoal is placed around the pipe inside the pit to retain moisture and improve conductivity. The salt acts as an electrolyte, while charcoal enhances soil conductivity and moisture retention. Installation Steps: Dig a pit of 2.5 – 3 m depth. Insert the GI pipe vertically (perforated up to 1.5 m). Surround it with alternating layers of salt and charcoal (approx. 150–200 kg total, depending on soil condition). Connect the earthing strip/wire (GI or copper) to the top using proper nuts, bolts, and clamps. Water the pit periodically to maintain moisture. ⚙️ Technical Specification ParameterTypical ValueMaterialHot Dip GI (Galvanized Iron)Length2 m / 3 mDiameter40 mm / 50 mm / 76 mmGalvanization Thickness80 microns (min.)Earth Resistance< 1 Ω to 5 Ω (depending on soil)Filling CompoundSalt & CharcoalConductor ConnectionGI Strip / Copper Strip / WireTesting StandardIS 3043 / IEC 62561-2 ✅ Advantages Economical and easy to install Suitable for normal soil conditions Provides long-term earthing reliability Improves safety by reducing potential difference during fault current Simple maintenance (requires periodic watering) ⚠️ Limitations Not ideal for rocky or high-resistance soil Requires regular watering for stable resistance Corrosion may occur over time (depending on soil chemistry) 📍 Application Areas Residential buildings Industrial plants DG sets and control panels Communication towers Commercial complexes Would you like me to create a catalogue page (A4 PDF) for this product in SN Engineering’s design format (with logo, images, and specifications)? I can also prepare a comparison chart between GI Pipe Earthing and Maintenance-Free Chemical Earthing for your brochure or quotation.
