Dual Fuel Kit availble in 125 kva, 250 kva, 350 kva
GAS GENERATOR Supplier| MSME Certified
Specialized in: PNG BASED GAS GENERATOR, LPG GAS GENERATOR BIO GAS GENERATOR/ Modification in Diesel DG
Dual Fuel Kit, RECD Kit
System Layout Dear Sir
This is with reference to the subject and your requirement for conversion of Diesel Gensets to dual fuel gas gensets.
As discussed, and explained we are pleased to offer you a Go GREEN Solution of FUELFLIP DUAL FUEL KIT for your current Diesel Gensets installed in your premises.
The benefits of conversion are not only in terms of cost saving by using GAS instead of Diesel but also the numerous benefits of reduced emissions thereby making a cleaner environment.
Benefits of conversion:
1. Reduced Emission:
The emission is considerably reduced and can be certified through a recognized government body. This helps in contributing to reducing pollution levels.
2. Reduced operating costs:
The cost of Gas is cheaper than diesel. Using PNG as the majority fuel, the kit considerably reduces the operating costs of the DG set. The Kit cost can be recovered within 1-1.5 Years (depending upon DG capacity) of operation with minimal running.
3. Statutory Compliances:
As per the NGT order Existing Diesel gensets need to be converted to partial gas usage in order to enable them to run. In case they are run only on diesel during this period, heavy penalties can be imposed and also the gensets can be sealed. After the fitment of the kit, the DG sets comply with this requirement.
4. No change in DG output:
The fitment of this kit does not Debate the capacity of the DG set. The DG continues to produce the same output with the same efficiency.
5. Zero Maintenance Kit:
The kit does not require any maintenance and is completely
As Discussed, and as per your requirements please find the rates as below
Sr. No Description Qty Dual Fuel Kit Price in INR
1 Dual Fueling Gas System Compatible for
125 KVA to 250 KVA Diesel Genset 1 450000
2 Dual Fueling Gas System Compatible for
250 to 500 KVA Diesel Genset 1 525000
3 Dual Fueling Gas System Compatible for
500 KVA to 750 KVA Diesel Genset 1 580000
4 Dual Fueling Gas System Compatible for
750 KVA to 1010 KVA Diesel Genset 1 1025000
5 Dual Fueling Gas System Compatible for
1010 kva to 1250 KVA Diesel Genset 1 1250000
6 Dual Fueling Gas System Compatible for
1250 KVA to 1500 KVA Diesel Genset 1 1450000
7 Dual Fueling Gas System Compatible for
1500 KVA to 2000 KVA Diesel Genset 1 1700000
Scope Of Work
Supply of the complete conversion kit along with control panel at site.
Installation of the kit on the dg set
Kit testing and dg on load commissioning after fitment of kit
All related activities to ensure gas kit is supplied, installed, and commissioned on the DG set.
Providing certificate of conformity stating that the gas kit makes the DG set compliant to the NGT order
Work Excluded in the Offer
All formalities related to gas procurement
Security deposit for gas supply and meter installation
Installation of Gas meter
Any other charges if any for the procurement of GAS connection/gas supply.
Supply and installation of complete internal gas pipeline fixture to ensure gas reaches the desired flow and pressure
Term and Condition
GST and Freight Extra
Quote Validity 10 Days
Prices Can be change as per site and market condition
Material Delivery 15 to 25 days
Air Cleaner Air Gas Mixer Turbocharge
BOQ OF DUAL FUEL SYSTEM
S.No. Material Description Qty
1 Gas train (filter, ZPR, MVDLE) 1 Nos.
Filter-50 micron
150 mbar zero pressure regulator
Electrically operated slow opening valve
Pressure regulator 1 Nos.
Inlet-2Bar, Outlet-150mbar
2
Air Gas mixer with MAS
1 Nos.
Venturi plate with housing to mix air/gas asper Bernoulli’s Law
3 Control panel with touch screen HMI 1 Nos.
PLC
HMI
MCB/relay/contractor etc
4(a.) pressure sensor 2 Nos.
0-1 Bar, 0-4 Bar
4(b.) Vibration sensor 1 Nos.
0-2 IPS
4(c.) Temperature Sensors 2 Nos.
5 Wire harness as per Engine 1 set
DUAL FUEL SYSTEM OPERATION
The Dual fuel system consists of a gas train with electrically operated slow opening valve. The train consists of a pressure regulator which is responsible for reducing the pressure of the PNG pipeline along with an Air Gas Mixtureconsisting of a venture plate with housing to mix the desired percentage of gas with air.
The system is controlled by a fully automated SELEC PLC consisting of MCB’s, Relays and contactors. The safety parameters are monitored in the PLC and we have Vibration sensors, temperature sensors and pressure sensors fittedon the DG set to maintain and monitor the levels.
The Gas train is governed by our patented software module and requires no manual intervention fo
